海康摄像头音频方案(播放音频文件+语音对讲+语音转发)-支持window/Linux-java版本

应用场景：

1. 有告警出现时，海康摄像头能自动播报（如：禁止游泳，请快速里离开）；

2. 在web页面点击“开始对讲”，能讲PC上的麦克风声音传输到海康摄像头进行对讲；点击“停止对讲”，海康摄像头停止对讲；

技术实现：
使用海康的SDK实现，nettyserver框架，提供webapi接口及websocket接口，兼容window、linux

警告：经测试linux稳定，window容易出现J 1031 C1 com.sun.proxy.$Proxy0.NET_DVR_EncodeG711frame(Lcom/sun/jna/Pointer;Lcommon/HCNetSDK$NET_DVR_AUDIOENC_PROCESS_PARAM;)Z (43 bytes) @ 0x00000000035202fc [0x000000000351ff00+0x3fc]

软件功能：

1. 集成海康SDK

2. WebAPI接口（PlayMedia，StartTalk，StopTalk），采集的是本地音频数据





3. WebSocket接口，讲web用户的音频数据转发到Server程序，通过SDK发送至海康摄像机

对讲初始化

H5->Server 发送指令 StartTalk::{ "ip": "192.168.3.2", "port": 8000, "name": "admin", "password": "yswy123456" }

Server->H5 返回指令 StartTalk::ACK_OK

Server->H5 返回指令 StartTalk::ACK_ERROE

开始对讲

H5->Server 发送指令 base64音频字符串

结束对讲

H5->Server 发送指令 StopTalk::

Server->H5 返回指令 StopTalk::ACK_OK

Server->H5 返回指令 StartTalk::ACK_ERROR

4.  链路检查超时退出SDK

测试报告

音频播放

开始对讲



结束对讲



方案内容





相关配置

1. 海康相机音频配置



 2. 将dll/so文件拷贝至系统目录下

window：C:/Windows/System32
linux: /usr/lib

3. pcm制作

1. 安装ekho-5.8.exe

2. 安装girl_xiaokun.exe

3. 运行ttsapp.exe

4.使用UltraEdit编辑,然后选中文件头的44个字节并剪切（因为退格键不管用），将这44个字节删掉，另存为pcm文件

核心代码

 // 开始音频文件
    static void StartMedia(Camera entity, String sfilePath)
    {
        lockAudio.lock();

        HCNetSDK.NET_DVR_COMPRESSION_AUDIO lpCompressAudio = new HCNetSDK.NET_DVR_COMPRESSION_AUDIO();
        boolean net_DVR_GetCurrentAudioCompress = hCNetSDK.NET_DVR_GetCurrentAudioCompress(entity.UserID, lpCompressAudio); if (!net_DVR_GetCurrentAudioCompress) return;
        byte byAudioEncType = lpCompressAudio.byAudioEncType;
        byte byAudioSamplingRate = lpCompressAudio.byAudioSamplingRate;
        byte byAudioBitRate = lpCompressAudio.byAudioBitRate;
        byte bySupport = lpCompressAudio.bySupport;
        System.out.println("音频编码类型=" + byAudioEncType + "  音频采样率=" + byAudioSamplingRate + "    音频码率=" + byAudioBitRate + "   bySupport=" + bySupport);

        NativeLong mr = hCNetSDK.NET_DVR_StartVoiceCom_MR_V30(entity.UserID, 1, null, null);
        File file = new File(sfilePath);

        FileInputStream inputStream = null;

        try
        {
            inputStream = new FileInputStream(file);

            Memory pInBuff = new Memory(file.length());
            pInBuff.clear();

            if (pInBuff != Memory.NULL)
            {
                int buffLen = 320; long currFileLen = 0; int readLen;
                byte[] buffer = new byte[buffLen];

                Memory pIB = new Memory(buffLen);
                while (currFileLen < file.length())
                {
                    entity.LastTime = System.currentTimeMillis();

                    readLen = inputStream.read(buffer);
                    pIB.write(0, buffer, 0, readLen);
                    currFileLen += readLen;
                    Memory pOutBuffer = new Memory(buffLen);
                    HCNetSDK.NET_DVR_AUDIOENC_INFO enc_info = new HCNetSDK.NET_DVR_AUDIOENC_INFO();
                    enc_info.in_frame_size = buffLen;
                    Pointer encoder = hCNetSDK.NET_DVR_InitG711Encoder(enc_info);
                    //
                    HCNetSDK.NET_DVR_AUDIOENC_PROCESS_PARAM param = new HCNetSDK.NET_DVR_AUDIOENC_PROCESS_PARAM();
                    param.in_buf = pIB;
                    param.out_buf = pOutBuffer;
                    param.out_frame_size = 160;
                    param.g711_type = 0;
                    boolean frame = hCNetSDK.NET_DVR_EncodeG711frame(encoder, param);
                    if (!frame)
                    {
                        int iErr = hCNetSDK.NET_DVR_GetLastError();
                        System.out.println("G711音频编码失败!iErr = " + iErr);
                        break;
                    }
                    frame = hCNetSDK.NET_DVR_ReleaseG711Encoder(encoder);
                    if (!frame)
                    {
                        int iErr = hCNetSDK.NET_DVR_GetLastError();
                        System.out.println("G711音频编码失败!iErr = " + iErr);
                        break;
                    }
                    boolean sendData = hCNetSDK.NET_DVR_VoiceComSendData(mr, pOutBuffer, 160);
                    if (!sendData)
                    {
                        int iErr = hCNetSDK.NET_DVR_GetLastError();
                        System.out.println("转发语音数据!iErr = " + iErr);
                        break;
                    }

                    Thread.sleep(20);
                }
            }
        }
        catch (Exception ex)
        {
            DataHelper.AddExceptionStackTrace("[Error] StartMedia", ex);
        }
        finally
        {
            if (null != inputStream) { try { inputStream.close(); } catch(Exception e) {} }

            lockAudio.unlock();
        }

        hCNetSDK.NET_DVR_StopVoiceCom(mr);
        System.out.println("读取完成");
    }
