（1）创建实时同步数据库
create database flink_gmall
（2）将Mysql.sql文件导入到Mysql中
source /opt/data/Mysql.sql
（3）查看数据库表
show tables;2、开启数据库的binlog
（1）在mysql中对需要进行实时数据监测的库开启binlog
sudo vim /etc/my.cnf #添加数据库的binlog server-id=1 log-bin=mysql-bin binlog_format=row binlog-do-db=flink_gmall #重启MySQL服务 sudo systemctl restart mysqld
（2）查询生成日志
cd /var/lib/mysql3、编写脚本
（1）创建项目
项目目录详述
目录 作用
（2）编写ODS代码
创建topic
bin/kafka-topics.sh --zookeeper hadoop102:2181/kafka --create --replication-factor 3 --partitions 6 --topic ods_behavior_db
工具类MyKafkaUtil
package com.lhw.utils;
import org.apache.flink.api.common.serialization.SimpleStringSchema;
import org.apache.flink.streaming.connectors.kafka.FlinkKafkaProducer;
public class MyKafkaUtil {
public static FlinkKafkaProducer getKafkaProducer(String topic){
return new FlinkKafkaProducer("hadoop102:9092,hadoop103:9092,hadoop104:9092",topic,new SimpleStringSchema());
}
}
反序列化函数CustomerDeserialization
package com.lhw.app.function; import com.alibaba.fastjson.JSONObject; import com.ververica.cdc.debezium.DebeziumDeserializationSchema; import io.debezium.data.Envelope; import org.apache.flink.api.common.typeinfo.BasicTypeInfo; import org.apache.flink.api.common.typeinfo.TypeInformation; import org.apache.flink.util.Collector; import org.apache.kafka.connect.data.Field; import org.apache.kafka.connect.data.Schema; import org.apache.kafka.connect.data.Struct; import org.apache.kafka.connect.source.SourceRecord; import java.util.List; public class CustomerDeserialization implements DebeziumDeserializationSchema{ @Override public void deserialize(SourceRecord sourceRecord, Collector collector) throws Exception { //1.创建JSON对象用于存储最终数据 JSONObject result = new JSONObject(); //2.获取库名&表名 String topic = sourceRecord.topic(); String[] fields = topic.split("\."); String database = fields[1]; String tableName = fields[2]; Struct value = (Struct) sourceRecord.value(); //3.获取"before"数据 Struct before = value.getStruct("before"); JSONObject beforeJson = new JSONObject(); if (before != null) { Schema beforeSchema = before.schema(); List beforeFields = beforeSchema.fields(); for (Field field : beforeFields) { Object beforevalue = before.get(field); beforeJson.put(field.name(), beforevalue); } } //4.获取"after"数据 Struct after = value.getStruct("after"); JSONObject afterJson = new JSONObject(); if (after != null) { Schema afterSchema = after.schema(); List afterFields = afterSchema.fields(); for (Field field : afterFields) { Object afterValue = after.get(field); afterJson.put(field.name(), afterValue); } } //5.获取 *** 作类型 CREATE UPDATe DELETE Envelope.Operation operation = Envelope.operationFor(sourceRecord); String type = operation.toString().toLowerCase(); if ("create".equals(type)) { type = "insert"; } //6.将字段写入JSON对象 result.put("database", database); result.put("tableName", tableName); result.put("before", beforeJson); result.put("after", afterJson); result.put("type", type); //7.输出数据 collector.collect(result.toJSONString()); } @Override public TypeInformation getProducedType() { return BasicTypeInfo.STRING_TYPE_INFO; } }
FlinkCDC的mainclass
package com.lhw.app.ods;
import com.lhw.app.function.CustomerDeserialization;
import com.lhw.utils.MyKafkaUtil;
import com.ververica.cdc.connectors.mysql.MySqlSource;
import com.ververica.cdc.connectors.mysql.table.StartupOptions;
import com.ververica.cdc.debezium.DebeziumSourceFunction;
import com.ververica.cdc.debezium.StringDebeziumDeserializationSchema;
import org.apache.flink.runtime.state.filesystem.FsStateBackend;
import org.apache.flink.streaming.api.CheckpointingMode;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import java.time.Duration;
public class MysqlFlinkCDC {
public static void main(String[] args) throws Exception {
// 1、获取执行环境
StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
env.setParallelism(2);
// // 2、开启CK并指定状态后端为FS
// // 2.1、制定存储ck地址
// env.setStateBackend(new FsStateBackend("hdfs://hadoop102:8020/flinkCDC"));
// // 2.2、指定ck储存触发间隔时间
// env.enableCheckpointing(5000);
// // 2.3、指定ck模式
// env.getCheckpointConfig().setCheckpointingMode(CheckpointingMode.EXACTLY_ONCE);
// // 2.4、指定超时时间
// env.getCheckpointConfig().setAlignmentTimeout(Duration.ofSeconds(1000));
// // 2.5、CK最小触发间隔时间
// env.getCheckpointConfig().setMaxConcurrentCheckpoints(2000);
// 3、通过FlinkCDC构建SourceFunction
DebeziumSourceFunction mysqlSource = MySqlSource.builder()
.hostname("hadoop102")
.port(3306)
.databaseList("flink_gmall") // set captured database
.tableList("flink_gmall.base_category1") // 如果不添加该参数,则消费指定数据库中的所有表
.username("root")
.password("123456")
.startupOptions(StartupOptions.initial())
.deserializer(new CustomerDeserialization())
.build();
// 4、使用CDC Source方式从mysql中读取数据
DataStreamSource mysqlDS = env.addSource(mysqlSource);
// 5、打印数据并将数据输入到kafka
mysqlDS.print();
String sinkTopic = "ods_behavior_db";
mysqlDS.addSink(MyKafkaUtil.getKafkaProducer(sinkTopic));
// 5、执行任务
env.execute("flinkcdcmysql3");
}
}
（3）运行测试
本地IDEA打印输出 & kafka集群消费
bin/kafka-console-consumer.sh --bootstrap-server hadoop102:9092 --topic ods_behavior_db
（4）检测变化
Mysql进行增改删工作
#新增数据 insert into flink_gmall.base_category1 values(18,"奢侈品"); #修改数据 update flink_gmall.base_category1 set name="轻奢品" where id = 18; #删除数据 delete from flink_gmall.base_category1 where id=18;
IDEA检测变化 & Kakfa集群检测变化
（5）模拟数据生成（检测整个库的变化）
①文件上传并运行
#文件上传 rz application.properties gmall2020-mock-db-2020-11-27.jar
②修改配置文件
修改对应的库名,用户名&密码
③运行数据生成项目文件
java -jar gmall2020-mock-db-2020-11-27.jar
④IDEA检测变化 & kafka消费数据变化
4、打包部署（1）修改代码
添加CK保存位置
package com.lhw.app.ods;
import com.lhw.app.function.CustomerDeserialization;
import com.lhw.utils.MyKafkaUtil;
import com.ververica.cdc.connectors.mysql.MySqlSource;
import com.ververica.cdc.connectors.mysql.table.StartupOptions;
import com.ververica.cdc.debezium.DebeziumSourceFunction;
import org.apache.flink.runtime.state.filesystem.FsStateBackend;
import org.apache.flink.streaming.api.CheckpointingMode;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import java.time.Duration;
public class MysqlFlinkCDC {
public static void main(String[] args) throws Exception {
// 1、获取执行环境
StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
env.setParallelism(2);
// 2、开启CK并指定状态后端为FS
// 2.1、制定存储ck地址
env.setStateBackend(new FsStateBackend("hdfs://hadoop102:8020/flinkCDC/flinkcdc-gmall-db"));
// 2.2、指定ck储存触发间隔时间
env.enableCheckpointing(5000);
// 2.3、指定ck模式
env.getCheckpointConfig().setCheckpointingMode(CheckpointingMode.EXACTLY_ONCE);
// 2.4、指定超时时间
env.getCheckpointConfig().setAlignmentTimeout(Duration.ofSeconds(1000));
// 2.5、CK最小触发间隔时间
env.getCheckpointConfig().setMaxConcurrentCheckpoints(2000);
// 3、通过FlinkCDC构建SourceFunction
DebeziumSourceFunction mysqlSource = MySqlSource.builder()
.hostname("hadoop102")
.port(3306)
.databaseList("flink_gmall") // set captured database
.username("root")
.password("123456")
.startupOptions(StartupOptions.initial())
.deserializer(new CustomerDeserialization())
.build();
// 4、使用CDC Source方式从mysql中读取数据
DataStreamSource mysqlDS = env.addSource(mysqlSource);
// 5、打印数据并将数据输入到kafka
mysqlDS.print();
String sinkTopic = "ods_behavior_db";
mysqlDS.addSink(MyKafkaUtil.getKafkaProducer(sinkTopic));
// 6、执行任务
env.execute("flinkcdcmysql3");
}
}
（2）打全量包
maven–>package
（3）上传脚本并运行
bin/flink run -m hadoop102:8081 -c com.lhw.MysqlFlinkCDC /opt/data/gmall-flinkcdc-mysql.jar
查看运行结果
查看WEB端的打印输出
（4）变更业务数据
运行业务数据的变更包
java -jar gmall2020-mock-db-2020-11-27.jar
查看运行结果（WEB端运行状态 & Kafka消费者消费消息）
查看WEB端的打印输出
5、代码运行步骤代码路径： /opt/module/data/mysql_cdc
启动步骤
#1、启动Flink bin/start-culter #2、启动kafka消费者 bin/kafka-console-consumer.sh --bootstrap-server hadoop102:9092 --topic ods_behavior_db #3、启动flink的WEB端 http://hadoop102:8081/ #4、启动flink任务 bin/flink run -m hadoop102:8081 -c com.lhw.MysqlFlinkCDC /opt/data/gmall-flinkcdc-mysql.jar
运行界面
6、源码&资料下载链接：https://pan.baidu.com/s/1mVRzQ4G5wqKkCAW74IzDOA 提取码：eni1
